The M210 is a continuous throughput mill that delivers fine and consistent plant material for cost-effective cannabis oil extraction or beautiful ground product. Add dry flower and trim of any size to the all-stainless steel construction and the M210 will produce a perfect, consistent grind with minimal powder. The unit has several screen options to customize output ranging from coarse to fine. The all stainless steel construction is easy to clean and ready for GMP facilities. Milled plant material can be caught in the included tote or an optional conveyor for fully automated workflows.
PRECISION-MILLED CANNABIS & HEMP FOR EXTRACTS AND GROUND PRODUCT.
| MILLING RATE: | |
| 110 lbs of flower per hour dry | 50 kg of flower per hour dry |
What’s In The Box?
| Mobius M210 Mill |
| Coarse Blending Screen – 6.35mm | 1/4” |
| Ultra Fine Rasp Screen – 1.6mm | 0.6″ |
| Medium Standard Milling Screen – 3.2mm | 1/8” |
Key Features
| 110 lbs per hour dry |
| 5 screen options ranging from coarse to fine output |
| Quality 304 stainless steel construction |
| Indoor non-marking casters for easy positioning |
| GMP-compliant and easy to clean |
| Ergonomic design for perpetual operation |
Screen Uses for the M210
The Mobius M210 is a continuous throughput mill with several screen options to customize output ranging from coarse to fine. The chart below outlines the specifications and intended use for each screen, though the Mill operates very differently depending on the strain and moisture. Some customers may use different screens on different strains for the same process.
| Colour-coded meanings |  = recommended use |
 = can be used depending on strain and moisture content |
 = not recommended for this product |
|
PART # |
DESCRIPTION | HOLE SIZE (mm) | HOLE SIZE (in) | TYPE | PRE-ROLLS | CO2 EXTRACTION | ETHANOL EXTRACTION | HYDROCARBON EXTRACTION |
| 10-02-002803 * CMPS600 |
COARSE BLENDING SCREEN | 6.4mm | 1/4″ | Perforated |  |
 |
 |
 |
| 10-02-002804 CMPS470 |
COARSE STANDARD MILLING SCREEN | 4.7mm | 3/16″ | Perforated |  |
|
 |
|
| 10-02-002805 * CMPS318 |
MEDIUM STANDARD MILLING SCREEN | 3.2mm | 1/8″ | Perforated | |
 |
 |
 |
| 10-02-002837 CMCS200 |
FINE RASP SCREEN | 2.0 mm | 5/64″ | Rasp |  |
|
|
|
| 10-02-002806 * CMCS160 |
ULTRA FINE RASP SCREEN | 1.6 mm | 1/16″ | Rasp | |
|
 |
|
* = screens included with each M210
Tech specs
| CONSTRUCTION: |
304 Stainless Steel |
| SPEED ADJUSTMENT: |
1-10 |
| NUMBER OF SCREENS: |
5 |
| FEED MOTOR: |
1/2HP |
| NUMBER OF MILLING BLADES: |
6 |
| POWER REQUIREMENTS: |
115V, 6AMPS |
| TOOL-LESS DISASSEMBLY: |
Yes |
| FITS THROUGH A 32″ DOOR: |
Yes |
| WIDTH: |
28″ |
| LENGTH: |
28″ |
| HEIGHT: |
52″ |
| WEIGHT: |
265LBS |
| WARRANTY: |
1 year |
| CERTIFICATIONS: |
CE and cLCus |
Power Requirements
Videos
Promos & In Action
► Installing Components
► Slow-Mo Grinding
► Slow-Mo Grinding Close Up
► Ground Product
► Removing Components
Academy Videos
How Tos & Tutorials
View more videos in the M210 Academy
Resources
& Downloads
MOBIUS MILL
M210
“I’ve got nothing but good things to say about the Mobius Mill. We’ve been able to scale up our pre-roll output to where we wanted it basically overnight. It’s helping us out a lot, and I’m sure can do the same for other producers as well.”
Andrew Van Wingerden
Double Dutch Farms
Further Reading
Perfect Extracts
& Ground Product
Supercritical Fluid Extraction produces the best product when the extraction vessel has an appropriately high packing density. Low packing density is typically the result of irregularly shaped plant material, resulting in slower and more costly extraction and inconsistent product quality. Milling plant material to a uniform size using the Mobius M210 makes extraction more efficient and leads to higher-quality oils. Product destined for ground consumption is consistently beautiful.
EASY TO CLEAN
& GMP-READY
The 304 stainless-steel construction with smooth internal surfaces and easy disassembly makes for fast cleaning and perfect integration with GMP-certified facilities.
Safety-First Design
The glove-friendly control panel with emergency stop is conveniently positioned at the front of the device within easy reach of the operator. Controls include variable speed, reset, forward, and reverse. The M210 is CSA-compliant for guarding and has a safety interlock on the access door.
Designed with
Automation in Mind
The Mobius M210 Mill can easily accommodate fully-automated workflows. The input hopper was designed to be fed by hand or conveyor. Consistently trimmed output with minimal powder can be collected in the included trim tote or caught by conveyor for automated packaging.
5 Different Milling Screens
The Coarse Blending Screen – 1/4”, Medium Standard Milling Screen – 1/8” and Ultra Fine Rasp Screen – 1.6mm are included with each Mobius M210 Mill. The following screens are also available.
FAQ
It’s specifically designed for cannabis and hemp. The combination of a massive 18” drum and 210 square-inch screens with a low-RPM churn-rate delivers unmatched through-puts and superior grind with zero heat gain or degradation.
Up to 110 lbs/hr dry with excellent particle distribution and minimal fines.
Yes. All stainless construction and surface preparation make this machine a fit for facilities producing GMP-certified products.
The application of GMP to the harvesting and production of cannabis means the end-user can be sure that what they buy is safe to consume and that it is consistent each time they buy it. For information about what it is and how it might be important to your workflow, check out our Ultimate Guide to a GMP-Certified Cannabis Trimming Workflow.
Yes. The Mobius M210 Mill has rasp- and perforated-style screens in 7 aperture sizes, making this mill ideal for all types of extracts and pre-rolls.
Tool-free disassembly and all stainless construction makes the M210 very easy to clean either by hand or with a pressure washer.
Yes, the M210 has guarding in place to make it compliant to worker safety regulations.
The M210 Mill runs on a standard 115V circuit drawing 6amps.
Mobius equipment is made in Canada.
Mobius equipment is available globally. We sell direct in Canada and through distribution in the USA. Contact us to start the conversation or to be directed to one of our Authorized Resellers.
